- CE-marking in accordance with EN 1504-6
- steel of stainless steel fibre grouting mortar with basaltic aggregates
- high flexural and shear strength and high impact resistance
- cement-bound
V15/50SF steel fibre basalt grout
highly flowable swelling grouting concrete, reinforced with steel fibre with high initial and final firmness
- granularity: 0-5 mm
- grouting height: 40-120 mm
- consumption: 2.200 kg/m³
- processing time at 20°C (68 °F): about 30 min
- expansion after 24 h: ≥ 0,1 %
- compressive strength after 28 d: ≥ 80 N/mm²
Produkteigenschaften
- high fluidity
- controlled swelling and strong locking connection between machine plate and concrete foundations
- high initial and final strength
- low water/cement ratio
- high flexural and shear strength and high impact resistance
- high impact, abrasion and grinding resistance
- impermeable to water and to great extent resistant against mineral oils and fuel
- steel fibre reinforcement and even more so stainless steel fibre reinforcement improve the thermal conductivity. Stressed caused by heat are fundamentally lower and are quickly dissipated
- basaltic grout with stainless steel fibres resistant to temperatures as high as 400°C (752°C)
- self-monitoring according to the DAfStb VeBMR directive
- satisfies the requirements of the type A1 construction materials (non-flammable) according to the ruling 2000/605/EG of the European Commission, September 26th 2000 (published in official journal, L258)
Anwendungsgebiete
- rail bearings and heavy foundations
- construction elements subject to particularly high stresses
- under particularly heavy burdens, usable with low grouting heights
- grouting of large dimension foundations
- grouting in areas of high temperature in steelworks and smelting works, up to 400 °C (752 °F) if used with basaltic aggregates and stainless steel fibres
- acts as reinforcement in occasions, in which due to constructive reasons reinforcement cannot be built in
