MH80 PCC-I-mortar

PCC-I concrete substitution system in accordance with ZTV-ING, part 3, section 4, DAfStb directive SIB and DIN EN 1504-3 for structurally relevant and non relevant repairs

  • concrete restoration in accordance to DIN EN 1504-3
  • ideal for application on horizontal surfaces
  • plastic additives, ready-to-use
  • high frost and de-icing salt resistance
  • usable under dynamic stress
  • MH02: corrosion protection and bonding bridge
  • granularity: 0-8 mm
  • layer thickness: >30 mm
  • consumption: 2,00 kg/(m²⋅mm)
  • processing time at 20°C (68 °F): about 60 min
  • pressure resistance after 28 d: ≥ 55 N/mm²
CE marking
MH80

Request test certificates

If you need further test certificates, please do not hesitate to contact us.
Tel. +49 201 685040
Email: pruefzeugnisse@pagel.de

Please enter your name.
Please enter a subject.
Please enter a valid phone number.
Please enter a message.

I have read the data protection declaration and I consent to the data I have provided being electronically collected and stored. My data is used only strictly for the processing and answering of my request.

You must accept the Terms and Conditions.

properties

  • ideal for application on horizontal surfaces
  • ready-to-use, just mix with water
  • allows vapour diffusion
  • reduces the penetration of CO2 and humidity (carbonation), to great extent impermeable to water, at the same time anti-corrosion and highly resistant against saponification

fields of application

  • restoration of PCC I (horizontal) surfaces in bridge and tunnel
  • coating of compensating surfaces in bridges and floors
  • repairing of fractures on concrete floors
  • base for further coatings and layers
